ERGO™ Precision Micro Tip Cutters 149 mm

SKU

RX 8233

Product Details

Precision micro tip cutters developed according to the scientific ERGO™ process
ESD safe ERGO™ handles with two-component combination, thermoplastic surface for comfortable grip, on tough polypropylene core for rigidity
Flush cut
Cutting capacity: 0.1 mm to 0.65 mm Cu
High-performance alloyed steel
Burnished finish
Numerically controlled machine grinding guarantees edge angle accuracy & contact, increases the tool's reliability & consistency
Precision induction-hardened edges 63-65 HRC
Screw joint minimises friction & maximises alignment of cutting edges
Bio spring limits the tension throughout the working cycle of the tool & can be adjusted to 3 different positions or removed
Ideal rework & close fine pitch applications

Documents

Manuals

Certificates

Technical Details

Grouped product items
Product																		Buy online
ERGO™ Flush Precision Cut Micro Tip Cutter 149 mm RX8233A	Micro Tip 10°	XS	Flush	0.1-0.6 mm	0.004-0.024 in	149 mm	5.9 in	22.3 mm	0.87 in	10.6 mm	0.41 in	7 mm	0.27 inch	7.2 mm	0.28 in	69 g	Dissipative
